Delta Electronics AC Motor Drive VFD-E User Manual
Page 141
Chapter 4 Parameters|
4-88
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
Group 5: Multi-step Speeds Parameters
05.00
1st Step Speed Frequency
Unit: 0.01
05.01
2nd Step Speed Frequency
Unit: 0.01
05.02
3rd Step Speed Frequency
Unit: 0.01
05.03
4th Step Speed Frequency
Unit: 0.01
05.04
5th Step Speed Frequency
Unit: 0.01
05.05
6th Step Speed Frequency
Unit: 0.01
05.06
7th Step Speed Frequency
Unit: 0.01
05.07
8th Step Speed Frequency
Unit: 0.01
05.08
9th Step Speed Frequency
Unit: 0.01
05.09
10th Step Speed Frequency
Unit: 0.01
05.10
11th Step Speed Frequency
Unit: 0.01
05.11
12th Step Speed Frequency
Unit: 0.01
05.12
13th Step Speed Frequency
Unit: 0.01
05.13
14th Step Speed Frequency
Unit: 0.01
05.14
15th Step Speed Frequency
Unit: 0.01
Settings
0.00 to 600.0Hz
Factory Setting: 0.00
The Multi-function Input Terminals (refer to Pr.04.05 to 04.08) are used to select one of the AC
motor drive Multi-step speeds. The speeds (frequencies) are determined by Pr.05.00 to 05.14
as shown in the following.
