Page 262: Baud 0, Refer to following diagram for details, Setting baud rate
Appendix B Accessories|
Revision June 2008, 04EE, SW--PW V1.11/CTL V2.11
B-25
72.2 [2.84]
57
.3
[2.
26]
14
.3
[0.
57]
59
.7
[2.
35]
3.5 [0.14]
35.8 [1.41]
CME-DN01
ADD1 ADD2
SP
500K
250K
125K
BAUD
MOD
NET
UNIT: mm(inch)
1
5
4
3
2
B.10.1.2 Wiring and Settings
Refer to following diagram for details.
CME-DN01
ADD1 ADD2
SP
500K
250K
125K
BAUD
MOD
NET
MAC address Date Rate
CAN-L
V+
Empty
Pin
CAN-H
V-
1: Reserved
2: EV
5: SG+
6: Reserved
7: Reserved
8: Reserved
3: GND
4: SG-
Setting baud rate
BAUD
0
Switch
Value
Baud
Rate
0 125K
1 250K
2 500K
Other AUTO
Setting MAC addresses:
use decimal system.
ADD1
ADD2
B.10.1.3 Mounting Method
Step1 and step2 show how to mount this communication module onto VFD-E. The dimension
on the left hand side is for your reference.
