Using PanelBuilder
Chapter 3
3-30
Symbol Type allows you to choose the type of ISA symbol. For a
complete listing of the ISA symbols and their on-screen appearance,
refer to Appendix D, ISA Symbols.
Buttons
Certain objects, such as the Control List Selectors and the Screen List
Selector, have two or more associated buttons. Use the Buttons menu to
configure these buttons.
Figure 3.26
The Buttons Menu for a Screen List Selector
23618
V1 Size: 1,068 Screen List Selector
OBJECT MENU: Move Look List Outer Text Utility Exit
"
"
"
"
"
Buttons
SCREEN 1
SCREEN 2
SCREEN 3
SCREEN 4
SCREEN 5
UP
DOWN
ENTER
Up Cursor Enable
Down Cursor Enable
Enter
Quit
To configure a button, select the button type from the Buttons menu, and
choose either Enable or Disable. Disabling the button removes it from the
screen. (You can’t disable both the Up Cursor and Down Cursor buttons).
Enabling the button opens a menu with the following choices:
Move positions the button on the screen independently of the other
components of the object.
Size defines the size of the button.
Function Key assigns a function key number (for Keypad terminals
only).
Margin Size defines the display size of a margin of touch cells for the
button (on Touch Screen terminals only).
