The Objects
Chapter 10
10-93
Decimal Point Position Address—This address is available only for
Numeric Data Display with Decimal Point and Numeric Data Display
with Decimal Point and Polarity. Define this address if you want the
PLC to control the decimal as defined in the Format menu. Configure
this address as you would a single Numeric Data Display with Decimal
Point.
Polarity Address—This address is available only for Numeric Data
Display with Polarity and Numeric Data Display with Decimal Point
and Polarity. Define this address if you want the PLC to control the
polarity of the data. Configure the address as you would a single
Numeric Data Display with Polarity.
Utility
The Utility menu lets you attach a name to and update the default values of
the Object List.
Exit
The Exit menu allows you to “Exit and Save Object”, “Save the Object
Only” or “Don’t save, just Exit”.
Button Operation
The Scrolling List object supports these buttons as defined in the Cursor
List object for control of the cursor position.
Except for the Enter button, these cursor buttons are active only when the
value of the Cursor Control Address for the Scrolling List is set at 0. If this
value is other than 0, the PLC controls the cursor.
The Enter button is always active, regardless of the state of the Cursor
Control Address.
Up Cursor moves the cursor to the previous state in the scrolling list. If
the cursor is at the top-most or first position in the list, pressing this
button has no effect.
Down Cursor moves the cursor to the next state in the scrolling list. If
the cursor is at the bottom-most or last position in the list, pressing this
button has no effect.
Page Up scrolls the list up by the number of Visible States defined. If
the cursor is at the top-most or first position in the list, pressing this
button has no effect.
