Creating a Sample Application File
Chapter 5
5-59
Figure 5.76
Screen 3
22109
V1 Size: 2,243 Screen: 3 PUMP Oct 15 1992 12:31
SCREEN MENU: Add Edit Move Delete Memorize Recall Options Exit
UP
DOWN
CROSSOVR
MAIN
OUTPUT
INPUT
BACKUP
_NNNN
_NNNN
_NNNN
_NNNN
_NNNN
MAIN
SCREEN
ON
ON
ON
ON
ON
PUMP_CONTROLS PRESSURE_(PSI):
P . U . M . P . G . C . O . N . T . R . O . L . S .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
O . N .
O . F . F .
2. Choose Exit and then Exit and Save Screen. This takes you back to
the Screens menu.
3. Press Esc to close the Screens menu and return to the File menu.
There is one more step to go before you’ve finished the sample application.
Save the Application File
Once you’ve finished your screens, you should save the file to disk.
1. Choose Exit from the File menu.
Figure 5.77
The Exit Menu
20110
FILE MENU: Screens Windows Options Communications Exit
FILE MENU: Screens Windows Options Communications Exit
Exit
Exit and Save file
Save file only
Don't Save, just Exit
Cancel Exit
