Troubleshooting

Appendix B

B-8

Problem

What to do

Cause

ББББББББББББ

ББББББББББ

While trying to download an application file,

a PROBLEM window appears stating: Error

code 208 was returned by the PassĆThrough

Utility."

ББББББББББББ

ББББББББББ

The PassĆThrough Utility has been unable to

establish DH+ communications with the PLCĆ5.

ББББББББББББ

ББББББББББ

Make sure the Programming Terminal DH+

Address" and the PLC DH+ Address" are

properly assigned.
Make sure that you have selected the proper

DH+ Hardware Driver" for your system, and that

the DH+ Driver Card Location" code is correct.

ББББББББББББ

ББББББББББ

Immediately after completing a PLCĆ5

PassĆThrough Download, a Minor Fault

Status bit is set in the PLCĆ5.

ББББББББББББ

ББББББББББ

The rack assignment configuration of the

application file downloaded to the PanelView did

not exactly match the application file that was

overwritten.

ББББББББББББ

ББББББББББ

Use the PLCĆ5 6200 Series software to clear the

Minor Fault; then reconfigure the PLCĆ5 to

recognize the new rack assignment.

Table B.G

PLC Series/Revision Requirements for PassĆThrough File Transfer

Processor

Series

Revision

PLCĆ5/11

All

PLCĆ5/15

N or later

PLCĆ5/20

All

PLCĆ5/25

J or later

PLCĆ5/30

B or later

PLCĆ5/40

E or later

B or later

PLCĆ5/60

E or later

B or later

PLCĆ5/250

All
