The Objects
Chapter 10
10-86
To create an Object List, select Object List in the Scrolling List selection of
the Add menu.
Figure 10.26
Selecting the Object List in the Add Menu
23718
SCREEN MENU: Add Edit Move Delete Memorize Recall Options Exit
Small
Push Buttons
Control Selectors
Screen Selectors
Indicators
Numerics
Text/Draw
Symbol
Bar Graphs
Time & Date
Screen Print Button
Local Message Display
ASCII Display
ASCII Input
Scrolling List Object List
Quit
Scrolling List
MultiĆState Indicator
Local Message
Numeric Data Display Standard
Quit
SCREEN MENU: Add Edit Move Delete Memorize Recall Options Exit
There are three types of Object Lists that you can choose from:
Multi-State Indicator Object List—This Object List is a list of
multi-state indicator objects that can display different states at any given
time. The Number of States that you specified for the Cursor List
determines the total number of multi-state objects you can define in a
single Object List. Defining this object is similar to defining the regular
Multi-State Indicator object, except that you can define only one set of
state text information (16 state text strings) per Multi-State Object List.
Local Message Object List—The Local Message Object List is a
listing of individual local message display objects. The total number of
Local Message objects in a single Object List depends on the Number of
States you specified for the Cursor List.
Numeric Data Display Object List—This Object List allows you to
configure multiple Numeric Data Display Objects in a list. If you select
this option for your Object List, you can choose among the following
Numeric Data Display options, similar to the single Numeric Data
Display Object:
