The Objects
Chapter 10
10-73
SHF—shifts the next character typed to upper case, or to the special
shift-key character for that key. To cancel the shift, press the SHF key
again.
Touch Screen Terminal, Small ASCII Input Object
The small ASCII input object has the following unique buttons:
Y Up cursor: moves the keyboard cursor up
B Down cursor: moves the keyboard cursor down
A Left cursor: moves the keyboard cursor to the left
" Right cursor: moves the keyboard cursor to the right
Table 10.X
Keyboard Displays for the ASCII Input Object
Display Components Touch Screen Terminal Keypad Terminal
Small Large Small Large
Keyboard characters Not configurable Not configurable Not configurable Not configurable
Keyboard Location configurable in the
Move menu
Vertical location only
configurable in Move menu
Location configurable in the
Move menu
Location configurable in the
Move menu
Characters within
scratchpad
Size configurable in the
Look menu
Size configurable in the
Look menu
Size configurable in the
Look menu
Size configurable in the
Look menu
Scratchpad Size configurable in Look
menu; location configurable
in Move menu
Size configurable in Look
menu; location configurable
in Move menu
Size configurable in Look
menu; location configurable
in Move menu
Size configurable in Look
menu; location configurable
in Move menu
Buttons Size fixed
Location configurable in the
Buttons menu
Not configurable Size fixed
Location configurable in the
Buttons menu
Function keys can be
assigned
Size fixed
Location configurable in the
Buttons menu
Function keys can be
assigned
Unique keys Y Up cursor
B Down cursor
A Left cursor
" Right cursor
SEL - Select
CAPS - Caps Lock
SHF - Shift
SEL - Select SEL - Select
Character Selection Move cursor to the desired
character with the cursor
keys and press SEL button
Press the desired character
on the touch screen to place
it in the data entry window
Move cursor to the desired
character with the cursor
keys and press SEL button
Move cursor to the desired
character with the cursor
keys and press SEL button
