Information and Alarm Windows
Chapter 7
7-16
Figure 7.15
The Messages Menu
20129
FILE MENU Screens Windows Options Communications Exit Windows
Alarm Window Enable
Information Window Enable
Terminal Fault Window
Alarm History Screen
Alarm Status Screen
Numeric and Security Entry Window
Quit
Alarm Window
Messages
Window Type
Window Look
Window Control Address
Options
Quit
Messages
Select Message 1 [ĆĆĆ] alarm number 1 is triggered
Create New Message 2
Delete Message
Copy Message to:
Import Message Text
Export Message Text
Quit
Once the number is assigned, press Enter; the Edit Message menu opens
with three alarm message options and a line for the message. The options
can be set differently for each message. Type the message and set the
options of your choice.
Figure 7.16
Edit Message Menu
Messages
Select Message 1 [ĆĆĆ] alarm number 1 is triggered
Create New Message 2
Delete Message
Copy Message to:
Import Message Text
Export Message Text
Quit
22132
Edit Message Number 2
Message Text alarm number 2 is triggered
Activate Audio Disable
Print Message Disable
Energize Relay Disable
Quit
Y
IMPORTANT: The maximum length of Alarm Messages in Version 3, 4
and 5 is 50 characters; and in Version 1 and Version 2 it is 36 characters.
The first time you create a message with a length of more than 36
characters, you will be warned that the application’s compatibility has
changed—the new application will only run on terminals with release 3.0
and later firmware.
The Alarm window has more features than the Information window and
greater priority as well.
