File Operations
Chapter 6
6-27
If both operations fail, the application file in the terminal may be
corrupted. The files in the computers will not be affected, so the best thing
to do is to try the download again immediately, but from only one
computer.
Uploading Over the Data Highway +
To upload, both PanelView and the PLC-5 must be active on the network
and in Run mode. Unlike download, the terminal will continue to function
in Run mode throughout the upload.
On the development computer, open the Transfer menu and choose
Pass-Through Upload from PanelView (DH+ and Remote I/O). Then use
the following menu to configure the PanelView terminal location on the
network, and initiate the upload.
Figure 6.25
PassĆThrough Upload from PanelView Window
22584
Pass-Through Upload from PanelView (DH+ and Remote I/O)
Start Upload
Load PanelView Location Data
PanelView Location Data
Rack
Group
Module (High/Low Byte)
PLC Type
PLC DH+ Address (0-77)
Local Bridge Address Not Used
Remote Bridge Address Not Used
Programming Terminal Configuration
Quit
The fields in this window are:
Start Upload. If the PanelView terminal location data and
programming terminal configurations are correct, the upload will begin.
If an error is detected, a warning message will be displayed.
Load PanelView Location Data allows you to get the location data
from an application file. The following window appears:
