PLC Programming Considerations
Appendix A
A-30
The following table displays the addresses for each of the additional
buttons.
Table A.M
Addresses for Additional Buttons in the Object List
Additional Buttons Command BLK
Transfer Address
Indicator State BLK
Transfer Address
PLC Address
AUTO MODE BI52/1 (Value = 1) N30:3/1 (Value = 1)
MANUAL MODE BI52/1 (Value = 0) N30:3/1 (Value = 0)
TOGGLE COMMAND BI52/3 N30:3/3
BI52/1 N30:3/1
SET COMMAND BI52/0 N30:3/0
BI52/1 N30:3/1
MANUAL ON BI52/4 N30:3/4
BI52/1 N30:3/1
MANUAL OFF BI52/5 N30:3/5
BI52/1 N30:3/1
NUMERIC KEYPAD
ENTER KEY FOR
STYLE NUMBER
BI52/6 N30:3/6
CHANGE STYLE NO.
CONTROL ADDR
BI53/0 Ċ 3/15 N30:4
The following table displays the addresses for the Object List PLC files.
Table A.N
Addresses for Object List PLC Files
Object List PLC Files PLC File Addresses PLC File Data Presets
ASSEMBLY STATION N31:1 through N31:57 1 through 57
LUXURY OPTION N32:1 through N32:57 1 through 57
STATION STATUS N33:1 through N33:57 1
OPTION COMMAND N34:1 through N34:57 1
OPTION STYLE NO. N35:1 through N35:57 100
When you have assigned all the addresses for the Object List PLC files,
you are ready to begin programming the PLC.
Step 3: Program the PLC
To program the PLC, follow the ladder diagrams shown in the following
pages.
