Creating a Sample Application File
Chapter 5
5-44
Figure 5.59
Control List Selector
22233
V1 Size: 1,919 Control List Selector
OBJECT MENU: Move Look
Buttons
List Outer Text Address Utility Exit
"
"
"
"
"
3.
Choose Buttons from the Object menu and then choose Up Cursor
(Decr Value).
4.
Choose Enable, and the Up Cursor (Decr Value) menu appears.
Figure 5.60
The Buttons Menu
20092
Buttons
Up Cursor (Decr Value)
Enable
Down Cursor (Incr Value)
Enable
Quit
Up Cursor (Decr Value)
Move
Size
Function Key
0
Edit Text
Move Text
Border
Single
Quit
From this menu:
a.
Move the cursor to Row 18, Column 23.
