Creating a Sample Application File
Chapter 5
5-19
Figure 5.27
The Exit Menu
22059
OBJECT MENU: Move & Size Look Text Screen
Exit
Exit and Save object
Save object only
Don't save, just Exit
Cancel Exit
M . A . I . N . G . S . C . R . E . E . N .
. . . . . . . . . . . . . . . . . . . . . . . . . .
Add the Second “Go To Screen” Button
Use the same steps to create the second button—with the following
changes:
1. Position the button at Row 5, Column 69.
2. Link function key 18 to the button.
3. Label the button PUMP CONTROLS.
4. Set the button to call Screen 3.
5. Exit and save the object.
Save the Screen
The screen now has a title and two buttons. To save it in the application
file:
1. Choose Quit in both the Screen Selectors and the Add menus.
2. Then choose Exit and Save Screen from the Exit menu.
The completed screen should look like the one below.
