<4. Display and Operations while Connected to GC8000>
4-5
IM 11B06C01-01E
Table List of each element function
Display Function and Display Information
GCM No. Indicates the GCM number (1 to 6).
Operation Mode Indicates the GCM operation mode (Run, Pause, or Stop).
Status Indicates the GCM status (Process or Manual).
Stream No. Indicates a stream number (1 to 31) being measured by the GCM.
In the Process Stop status, the stream number is empty.
In the Manual status, the item itself is hidden.
Measurement Status Indicates the current measurement status of GCM (such as stream sequence,
stream specification, and calibration/validation).
If the stream specification is selected, the current number of measuring times and
the number of times to measure are indicated. (Example: Stream specification
(7/10))
Also, if the number of times to measure is zero (Continuous), “Stream specification
(Continuous)” is displayed.
In the Manual status, this item itself is hidden.
Method No. Indicates the current method number (1 to 6) of the GCM.
In the Process Stop status, the stream number is empty. In the Manual status, the
item itself is hidden.
GCM Alarm Status Displays the alarm status of GCM.
l Green: No alarm
l Yellow: Level-2 alarm has occurred.
l Red: Level-1 alarm has occurred.
When you double-click this indication, the Alarm Status window of the GCM
appears.
System number Indicates a system number (1 to 6) of the GCM.
System Operation mode Indicates the system operation mode (Run, Pause, or Stop).
Elapsed time/System
Analysis cycle
Indicates the time (in seconds) that has elapsed from the start of system analysis
and the cycle (in seconds) of SYS analysis.
In the Stop operation mode, “ 0/ ---” is displayed. While in the Manual Run mode,
“100/ ---” is displayed and only the elapsed time is updated.
Elapsed time bar graph Indicates the progress of measurement (in percentage) in a bar graph based on
the elapsed time and the GCM analysis cycle. The green area increases when the
measurement proceeds.
If the GCM analysis cycle is greater than the system analysis cycle, the odd-
numbered analysis is turned green and the even-numbered analysis is turned aqua.
Change Operation Mode
button
Displays the dialog box used to change the operation mode. You can change the
operation mode of the corresponding GCM. You cannot select this option in the
Manual status. See Subsection 4.2.5 “Change Operation Mode.”
Display Analysis Result
button
Displays the latest analysis result window of the corresponding GCM. The Latest
Analysis Results window is displayed for each GCM. You can open a multiple
number of Latest Analysis Results windows for GCM simultaneously. See
Subsection 4.2.6 “Latest Analysis Results window.”
When you double-click any GCM display area, other than “GCM Alarm Status” area, the Change
GCM Number dialog box opens. See Subsection 4.2.4 “Selecting GCM No.”
