<5. Display and Operations while Connected to GC1000 Mark II>
5-28
IM 11B06C01-01E
(3) Choose the time frame in which the history chromatogram to display is included and click
the OK button.
A list of all chromatograms contained in the selected time frame appears.
F5-3-9.ai
(4) Choose the time frame in which the history chromatogram to display is included and click
the OK button.
A list of all chromatograms contained in the selected time frame appears.
F5-3-10.ai
(5) Choose the chromatogram to be displayed and click the OK button.
This returns you to the dialog box in step (1).
(6) Click the OK button. The specified chromatogram is displayed.
The legend display area shows the following detector number and measurement date and
time.
08/10 16:09 H1
H1: history chromatogram 1
H2: history chromatogram 2
Month Day Hour Minute
TIP
If a time earlier than 24 hours prior is specified in step (3), processing may take some time, depending on the
amount of data.
