l Configuration
The display of the Analyzer Status window differs depending on the analyzer type. See Chapter 4
for GC8000. See Chapter 5 for GC1000 Mark II. See Chapter 6 for ASIU.
For GC8000
Analyzer ID/Tag name
Alarm Status Elapsed time bar graph Elapsed time/Analysis cycle
Status
Operation Mode
Measurement status
Select GCM combo box
F0309.ai
For GC1000 Mark II
Analyzer ID/Tag name
Measurement status
Alarm Status Elapsed time bar graphh Elapsed time/Analysis cycleycle
Status
Change Operation Mode button
Display Analysis Result button
F0310.ai
Operation Mode
For ASIUs
Analyzer ID/Tag name
Alarm Status
Contact Input Status
Contact Output Status
F0311.ai
3.3 Changing User Level
There are three user levels for analyzers. As the default, user level “A” which only permits
confirmation of the operation window(s) is set.
If you wish to change the user level to one allowing operation control, enter a password to
change to the desired user level.
Please refer to User’s Manual of GC8000 (IM 11B08A01-01E) or Password Manual (IM
11B03A03-07E).
