A-7
IM 11B06C01-01E
Menu Name
Command Name
Function
File
Save Chrom.
Saves the chromatogram displayed in the window to the hard
disk or a floppy disk.
Exit
Exits the Chromatogram window.
Scale
Zoom In
Enlarges chromatogram display.
Zoom Out
Reduces chromatogram display.
Part Enlargement
Specifies a range of chromatogram display and enlarges it.
Full Disp
Displays the entire chromatogram.
Auto Scale
Switches ON/OFF of auto-scale.
Graph
Pen Select
Sets up a chromatogram to display.
Timing mark
Switches visible/invisible status of mark information.
Temp/Pressure Display
Displays temperature data of a chromatogram.
Option
Grid
Snap Shot - Snap 1
Stores a currently displayed window in memory or displays
window data stored in memory.
Snap Shot - Snap 2
Stores a currently displayed window in memory or displays
window data stored in memory.
Snap Shot - Clear
Erases the contents of the window stored using the Snap 1 or
Snap 2 command.
Cursor Pos.
Switches visible/invisible status of the time and voltage value of
the mouse cursor position on a graph.
Peak Display On the
chromatogram
Indicates mark information for peak display above the peak
position.
Peak Display Under the
chromatogram
Indicates mark information for peak display below the peak
position.
Help
Contents
Displays the contents of Help of the Chromatogram window.
Help Search
Displays Help on the basis of the keyword entered.
n
Analyzer Configuration Windows
T16A.ai
System
Exit
Help
help
