<3. Overview Window>
3-15
IM 11B06C01-01E
(3) Enter the file name for the setting parameters to be saved under, preceding the extension
“.px1” (“.pr7”), and click on the “Data” directory which is preserved for saving.
Example: Where “system01” is specified as the file name:
system01. pr7
(4) Click the OK button.
The AS_MAIN dialog box appears, indicating that uploading the setting parameters from the
analyzer is taking place.
F0323.ai
When all the setting parameters have been saved to the file, the FileMan dialog box
appears.
Note that uploading the parameters to the Engineering Terminal takes about 10 seconds.
F0324.ai
(5) Click the OK button.
This completes the uploading process.
HELP !
If you wish to interrupt the uploading of setting parameters,
• Click on the Interrupt command in the File menu.
A Confirmation dialog box appears.
• Click the Yes button.
n
Downloading
To download setting parameters from the Engineering Terminal to an analyzer, do the following:
CAUTION
If the parameters have been written to an analyzer, exit the Engineering Terminal and then restart
it. If you do not restart, data cannot be displayed properly.
5th Edition : Nov. 16, 2011-00
