Page 189

A-8
IM 11B06C01-01E
n
Alarm (Common to Alarm Status and Alarm History Windows)
T09A.ai
View
Detail
Help
v Alarm Status
Alarm History
PCAS Alarm History
GCM
Clear Status
Clear History
Exit
View
Making External DI alarm description
Help
ALL(A)
v GCM1(1)
GCM2(2)
GCM3(3)
GCM4(4)
GCM5(5)
GCM6(6)
Menu Name
Command Name
Function
Display
Alarm Status
Displays the Alarm Status window.
Alarm History
Displays the Alarm History window.
PCAS Alarm History
Displays the PCAS’s Alarm History window.
Select GCM
Allows you to select THE GCM whose alarms are displayed. If
ALL is selected, all alarms that have occurred in the GCM are
displayed.
Clear Status
Clears the alarm statuses of the analyzer.
If ALL is selected in THE GCM selection, all alarm statuses of the
GCM will be cleared. If any of CGM1 to GCM6 is selected, the
alarm statuses of the GCM concerned will be cleared.
Clear History
Clears the alarm history of analyzer.
If ALL is selected in THE GCM selection, all alarm histories
provided for the GCM will be cleared. If any of CGM1 to GCM6
is selected, the alarm histories of the GCM concerned will be
cleared.
Close
Closes the Alarm Window.
Detailed
Display
Displays the Alarm Detail description dialog. On this dialog,
entering an alarm number and clicking the Execute button
causes the Alarm Detail Window to appear.
Making External DI
alarm description
Displays the Making External DI alarm description dialog. On this
dialog, you can create a message or detailed alarm description
to be displayed if an external DI alarm occurs.
Help
Help
Displays the ASET Instruction Manual.
n
Analysis Results
T10A.ai
File
Open History Ctrl + O
Open History (Analyzer)
Close History Ctrl + W
Window
v Latest Analysis Results
Concentration Analysis History
Retention Time History
Lab Analysis History
Calibration Coefficient History
File Analysis Results
File Concentration Analysis History
File Retention Time History
File Lab Analysis Results
File Calibration Coefficient History
Display Item
Select Display Item
Select SYS
Graph
GraphA
GraphB
GraphC
User Level
v User Level A
User Level B
User Level C
User Level C+
Help
Help
Save As Ctrl + S
Setting the Number of History Data
Auto Update
Exit Alt + F4
File
Open Ctrl + O
Close Ctrl + W
Save As
Save Ctrl + S
Exit Alt + F4
or
v GCM
SYS1
SYS2
SYS3
SYS4
SYS5
SYS6
5th Edition : Nov. 16, 2011-00
