A-10
IM 11B06C01-01E
n
Graph
T13A.ai
Fail
Close
Graph
Make
End
Help
Contents
Search by Keyword
Menu Name
Command Name
Function
Close
Close
Closes a graph window.
End
End
End a graph window.
Graph
Make
Plots concentration analysis history, Retention time history, file
concentration analysis history, or file Retention time history into
a graph.
Print the graph
Help
Contents
Displays the contents of Help of the Analysis Results window.
Help Search
Displays Help on the Analysis Results window on the basis of the
keyword entered.
n
ASIU Operation Window
T15A.ai
System
Close
DO Set
DO01 (1)
DO02 (2)
DO03 (3)
DO04 (4)
DO05 (5)
DO06 (6)
DO07 (7)
DO08 (8)
DO09 (9)
DO10 (A)
DO11 (B)
DO12 (C)
DO13 (D)
DO14 (E)
DO15 (F)
DO16 (G)
Help
Contents
Help Search
Menu Name
Command Name
Function
System
Close
Close ASIU operation window.
DO Set
DO01
¦
DO16
ON/OFF DO01 (to DO16).
Note: [DOxx] is displayed as [TAG#] when Tag# is set, as
[TAG#/Signal] when Tag# and Signal are set.
Help
Contents
Displays the contents of Help of the ASIU Operation Window.
Help Search
Displays Help of the ASIU Operation window on the basis of the
keyword entered.
