<5. Display and Operations while Connected to GC1000 Mark II>
5-37
IM 11B06C01-01E
5.4.1
Displaying and Exiting the Analysis Results Windows
When you open the analysis results window, the Latest Analysis Results window appears.
CAUTION
Only one analysis results window can be displayed at a time.
n
Displaying (the Latest Analysis Results Window)
Specify an analyzer ID in the Overview window, and then command the analysis results window
to be displayed. When an analysis results window is opened from the Overview window, the
Latest Analysis Results window appears.
SEE ALSO
Section 3.6, “Selecting Analyzer” for specifying an analyzer ID
l
Operation procedure
Click on the Analysis Results command in the Window menu.
• This operation can also be conducted by clicking the Analysis Results Window Display
button ( ) on the toolbar.
The Latest Analysis Results window is then displayed.
TIP
If the analysis results windows are reduced to icons and registered for the ASET group, they can be opened
separately. However, it should be noted that the displayable analysis results when a registered analysis results
window is opened without activating the Overview window are limited to the range of data stored in the PC.
F5-4-2.ai
5th Edition : Nov. 16, 2011-00
