<5. Display and Operations while Connected to GC1000 Mark II>
5-33
IM 11B06C01-01E
n
Enlargement
l
Operation procedure
Click on the Zoom in button ( ) on the toolbar.
The scales for the x and y axes are enlarged by one division respectively based on the center of
the Enlargement Display area.
• You can also achieve the same results using the Zoom in command in the Scale menu.
n
Reduction
l
Operation procedure
Click on the Zoom out button ( ) on the toolbar.
The scales for the x and y axes are reduced by one division respectively based on the center of
the Enlargement Display area.
• You can also achieve the same results using the Zoom out command in the Scale menu.
n
Partial Enlargement
l
Operation procedure
(1) Click on the Partial Zoom button ( ) on the toolbar.
(2) Drag the start and end points of the area you wish to enlarge on the Overall Display area or
the Enlargement Display area.
Start points
End points
F5-3-15.ai
5th Edition : Nov. 16, 2011-00
