<4. Display and Operations while Connected to GC8000>
4-54
IM 11B06C01-01E
l Displaying concentration analysis (history) results from the past
1) Select Concentration Analysis History Window in the Window menu, or the Concentration
Analysis History Window tab to display the Concentration Analysis History window.
2) Select SYS Number Select in the Display Item menu, or the system number or GCM of the
concentration analysis result you want to display from the system number select combo box
on the toolbar.
3) Select Open History in the File menu, or the Open History command button on the toolbar to
open the history setting dialog box.
4) From the radio button selecting Display from Latest or Display from History, select Display
from History, then apply it by pressing the OK button.
5) From the Display from History combo box, select the desired year and month, and apply it
using the OK button.
Figure 4.65 Year and month setting dialog box
6) Select a desired date from the analysis date setting dialog box, then apply it by pressing the
OK button.
Figure 4.66 Date setting dialog box
7) Select a desired time from the analysis time setting dialog box, then apply it by pressing the
OK button.
Figure 4.67 Time setting dialog box
