Functions and display information of elements
Display Item
Function and Display Information
Title bar
Shows the object analyzer ID number as well as the window name.
Analysis Start Time
Indicates the time of day at which analysis of the displayed data was
started.
Stream#-Peak#-Peak
Name
Indicates the stream number, peak number, and peak name, delineated by
“-”. For results obtained in Lab mode or Manual mode, the stream number
indicated is “32.”
Concentration Value
Indicates the concentration value in %, ppm or "No unit" as a peak-basis
analysis result.
CAUTION
If the peak setting is modified from the analyzer unit side while the Latest Analysis Results
window is being displayed, exit the Engineering Terminal and then reboot it. Continuing to
display the Latest Analysis Results window without a reboot may cause the analysis results to be
incorrect.
n
Display
l
Operation procedure
Click the button (Analyzer Status window) of the analyzer for which you wish to display the
Latest Analysis Results window.
The Latest Analysis Results window appears.
n
Exiting
l
Operation procedure
Click on the Close command in the Control menu in the Latest Analysis Results window.
The Latest Analysis Results window is closed.
