Operator’s Manual
310
WE-OM-E Rev A
CustomDSO Basic Mode
The Basic CustomDSO mode offers eight Action buttons, each of which can call a different setup
when touched. The "Action Definition" dialog is used to enter a CustomDSO setup file name by
means of the pop-up keyboard.
Checking the Execute scripts asynchronously checkbox allows
scripts to run in a separate process. Thus, the scope application can perform another function while the script
is being executed.
By clicking the checkbox , the eight CustomDSO buttons
will continue to be available at the bottom of the screen after you close the CustomDSO dialog.
Furthermore, they will appear automatically each time the scope is powered up.
Editing a CustomDSO Setup File
If the file does not exist, touch the Edit button ; a dialog will appear for you to create
the file. If the file does already exist, the Edit button enables you to modify it. The Edit button allows
you to edit the file that is named in the Setup file to recall field, and not the file of the setup that the
instrument is currently in, unless these happen to be the same.
