Operator’s Manual
178
WE-OM-E Rev A
rising edges. For both cases,
widths of all waveform pulses
are averaged for the final
result.
Width@level Width measured at a specific
level. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
WidthN Width measured at the 50%
level and negative slope. Standard parameter.
X at max Determines the horizontal
axis location of the maximum
value between the cursors. Restricted to time and
frequency waveforms
only.
X at min Determines the horizontal
axis location of the minimum
value between the cursors. Restricted to time and
frequency waveforms
only.
X at peak The value of the nth highest
histogram peak. Applies only to
histograms.
Available with JTA2 and
XMAP options.
Standard in
DDA-5005A.
