The advantage of selecting Div is that the trigger point will remain on the grid as you increase the
timebase; whereas, if Time is selected, the trigger point could move off the grid.
Note: Regardless of whether you select Time or Div, the "Delay" shown in the timebase setup dialog always indicates time.
However, when Div is selected for Delay In, the delay in time is scaled proportional to the change in timebase, thereby
keeping the division on the grid constant.
1. In the menu bar touch Utilities; then touch Preferences in the drop-down menu.
2. Touch
the Acquisition tab.
3. Under Delay Setting constant in:, touch either the Div or Volts button.
E-mail
Before you can send e-mail from the scope, it must first be configured.
1. In the menu bar touch Utilities, then Preference Setup... in the drop-down menu.
2. Touch
the E-mail tab.
3. Choose an e-mail server protocol: MAPI (Messaging Application Programming Interface)
is the Microsoft interface specification that allows different messaging and workgroup
applications (including e-mail, voice mail, and fax) to work through a single client, such as
the Exchange client included with Windows 95 and Windows NT. MAPI uses the default
Windows e-mail application (usually Outlook Express). SMTP (Simple Mail Transfer
Protocol) is a TCP/IP protocol for sending messages from one computer to another
through a network. This protocol is used on the Internet to route e-mail. In many cases no
account is needed.
4. If you chose MAPI, touch inside the Originator Address (From:) data entry field and use
the pop-up keyboard to type in the instrument's e-mail address. Then touch inside the
Default Recipient Address (To:) data entry field and use the pop-up keyboard to enter
the recipient's e-mail address.
5. If you chose SMTP, touch inside the SMTP Server data entry field and use the pop-up
keyboard to enter the name of your server. Touch inside the Originator Address (From:)
data entry field and use the pop-up keyboard to type in the instrument's e-mail address.
Then touch inside the Default Recipient Address (To:) data entry field and use the
pop-up keyboard to enter the recipient's e-mail address.
6. You can send a test e-mail text message by touching the Send Test Mail button. The test
message reads "Test mail from [name of scope's email address]."
Acquisition Status
For each general category of scope operation, you can view a summary of your setups. These
dialogs are not accessible through the Utilities menu, but are instead accessed from the menu bar
drop-down menus. The categories are as follows:
y Vertical -- select Channels Status . . . from drop-down menu
y Timebase -- select Acquisition Status . . . from drop-down menu
y Trigger -- select Acquisition Status . . . from drop-down menu
y Math -- select Math Status . . . from drop-down menu
In addition to these dialogs, summaries are also provided for XY setups, memory (M1-M4) setups,
