Wave Expert
WE-OM-E Rev A
235
dialog is open (docked).
RHS Dialog Only For Math setup displays, sends only the
right-hand side
mini-dialog
Example RHS dialog .
7. Touch the Print Now button .
Date & Time
The instrument gives you the choice of manually setting the time and date or getting it from the
Internet. If you elect to get the time and date from the Internet, you need to have the scope
connected to the Internet through the LAN connector on the rear panel. You can also set time
zones and daylight savings time.
To Set Time and Date Manually
1. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch
the Date/Time tab.
3. Touch inside each of the Hour, Minute, Second, Day, Month, and Year data entry fields
and enter a value, using the pop-up numeric keypad.
4. Touch the Validate Changes button.
To Set Time and Date from the Internet
The Simple Network Time Protocol (SNTP) is used.
1. Ensure that the scope is connected to the Internet through the LAN connector at the rear of
the scope.
2. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
3. Touch
the Date/Time tab.
4. Touch the Set from Internet button.
