Operator’s Manual
270
WE-OM-E Rev A
OutResult.DataArray(False) = newArray ' signed long integer data output
Example Parameter Function Script: RMS of a waveform
' Example script to produce a parameter.
' This script calculates the root mean square
' of the input waveform.
' Note that a trace of nominal length 1000 has data from
' 0 to 1001. The 1001st point is not visible, so you
' normally use points 0 to 1000,
' giving 1001 points and 1000 intervals between points.
startData = 0
endData = InResult.Samples
LastPoint = endData - 1 ' because the last point is invisible.
ReDim newArray(InResult.Samples) ' to store the results
unscaledData = InResult.DataArray(True)
' InResult.DataArray(False) provides
' integer data from -32768 to 32767.
' InResult.DataArray(True) provides real data
' in the same unit as the vertical scale of the trace.
Total = 0
For i = 0 To LastPoint
Total = Total + (unscaledData(i)) ^ 2
Next
NewArray(0) = Sqr (Total / (LastPoint + 1)) Place the result in the zeroth
element.
OutResult.ValueArray(True) = newArray ' integer data output
The default waveform function script: explanatory notes
InResult.Samples is the number of points in the incoming waveform.
InResult.DataArray(Boolean) (or InResult1.DataArray or InResult2.DataArray) is the array of input
data. If the Boolean is True you get scaled real data in the units of the trace. If the Boolean is false
you get unscaled integer data in the range -32768 to + 32767.
The value of InResult.Samples is the total number of data in a trace. It is two more than the nominal
value given on the screen. The first point DataArray(0), coincides with the left edge of the screen,
