Teledyne LeCroy WaveExpert 100H Operators Manual - Manual (Page 161)

Wave Expert
WE-OM-E Rev A
159
crossing after left cursor.
Can measure propagation
delay between two signals by
triggering on one and
determining delay of other.
Delta delay delay: Computes time
between 50% level of two
sources. Time between midpoint
transition of two
sources Standard parameter.
Dperiod@level Adjacent cycle deviation
(cycle-to-cycle jitter) of each
cycle in a waveform Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Dtime@level t at level: Computes
transition between selected
levels or sources. Time between transition
levels of two sources, or
from trigger to transition
level of a single source
This measurement
gives the time of the
source 2 edge minus
the time of the source 1
edge.
Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Standard parameter.
Duration For single sweep waveforms,
dur is 0; for sequence
waveforms: time from first to
last segment's trigger; for
single segments of sequence
waveforms: time from
previous segment's to
current segment's trigger; for
waveforms produced by a
history function: time from
first to last accumulated
waveform's trigger. Time from first to last
acquisition: for average,
histogram or sequence
waveforms Standard parameter.
Duty@level Percent of period for which
data are above or below a
specified level. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
