Wave Expert
WE-OM-E Rev A
27
Vertical Resolution: 14 bits up to 17 bits with enhanced resolution (ERES)
Sensitivity: 1 mV/div to 1 V/div
Offset Range: -1 V to +1 V
Horizontal System
Timebases: 2 timebases common to all 4 channels are available; Sequential (SEQ) and
High-stability Coherent Interleaved Sampling (HCIS)
Maximum Sampling Rate: 10 MS/s (CIS), 500 kS/s (SEQ)
Math & Zoom Traces: 4 independent zoom and 4 math/zoom traces standard; 8 math/zoom
traces available with XMAP (Master Analysis Package) option
Timebase Jitter (typical): 210 fs rms (CIS); 0.8 ps rms (SEQ)
Acquisition System
Memory Options:
Memory
Option
Sequential Coherent Interleaved
Standard 100 K/channel 4 M/channel
M Memory Option 100 K/channel 128 M/channel, 510 M/
1 channel
Acquisition Processing
Averaging: Summed averaging to 1 million sweeps; Continuous averaging to 1 million sweeps
Envelope (Extrema): Envelope, floor, roof for up to 1 million sweeps
Triggering System
Modes: normal, prescale, TDR (internal)
Sources: front panel SMA connectors for direct and prescale, internal 1 MHz clock for TDR
Coupling: DC 50 ohms for direct trigger, AC 50 ohms for prescaled trigger
Vertical Find Scale: Automatically sets the vertical sensitivity and offset for the selected channels
to display a waveform with maximum dynamic range.
Color Waveform Display
Type: Color 10.4-inch flat panel TFT LCD with high resolution touch screen
Resolution: SVGA; 800 x 600 pixels
Real-time Clock: Date, hours, minutes, and seconds displayed with waveform; SNTP support to
synchronize to precision internet clocks
Number of Traces: Maximum of eight traces; simultaneously displays channel, zoom, memory,
