Operator’s Manual
234
WE-OM-E Rev A
E-Mail
The instrument also gives you the option to e-mail your screen images, using either the MAPI or
SMTP protocols. Before you output to e-mail from the Utilities dialog, you first have to set up the
e-mail server and recipient address in Preference Setup.
To Send E-mail
1. In the menu bar touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch
the Hardcopy tab, then the E-mail button.
3. Touch inside the File Format data entry field and select a graphic file format from the
pop-up menu.
4. Under Colors, touch the Use Print Colors checkbox if you want the traces printed on a
white background. A white background saves printer toner.
5. Touch the Prompt for message to send with mail checkbox if you want to include
remarks with the image.
6. Touch inside the Hardcopy Area field and make a selection from the pop-up menu:
Grid Area Only Sends only the waveforms and whatever
annotation is contained in the grid.
DSO Window Sends the grid area plus open dialogs.
Full Screen In case the scope display is windowed
(reduced), sends the scope UI
and revealed desktop.
Menu Only Sends only the menu bar at the top of the scope.
Message Line Only Sends only the status line at the bottom of the
screen.
Docked Dialog Only Sends only the dialog area of the screen, if a
