Teledyne LeCroy WaveExpert 100H Operators Manual - Manual (Page 174)

Operator’s Manual
172
WE-OM-E Rev A
Period@level Period at a specified level
and slope for every cycle in
waveform. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Phase Phase difference between
signal analyzed and signal
used as reference. You can
set the output type to
percent, degrees, or radians.
After setting up the
reference, touch the More
tab for signal setups. Phase difference
between signal and
reference Standard parameter.
Pop@X Population at bin for
specified horizontal
coordinate. You can place
the cursor at any bin and use
either Absolute, Reference,
or Difference cursor shape. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
PW50 Average pulse width at the
50% point between the local
baseline and the local peak
or trough. Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
PW50- Average pulse width at the
50% point between the local
baseline and the local
trough. Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
PW50+ Average pulse width at the Hysteresis argument
