Operator’s Manual
176
WE-OM-E Rev A
Standard parameter.
TAA Average peak-to-trough
amplitude for all local
features.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
TAA- Average local
baseline-to-trough amplitude
for all local features.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
TAA+ Average local
baseline-to-peak amplitude
for all local features.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with DDM2
option.
Standard in
DDA-5005A.
TIE@level Difference between the
measured times of crossing
a given slope and level and
the ideal expected time. For
Slope you can choose
positive, negative, or both.
For output units you can
choose time or unit interval
(UI). A unit interval equals
one clock period.
The Virtual Clock setup gives
you a choice of Standard
(1.544 MHz) or Custom
reference clocks.
Cutoff Freq =
(1/1.667e3) x Clock
Freq Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
