Operator’s Manual
104
WE-OM-E Rev A
The default settings are as follows:
Vertical Timebase Trigger
100 mV/div 1.00 ns/div Prescale
0 V offset 1.0 KS, -12 ns delay
Sequential acquisition Auto trigger mode
Saving Screen Images
You can send images to a hard copy printer or to storage media. Both types of output are done from
the same dialog.
1. In the menu bar, touch Utilities, then Utilities Setup... in the drop-down menu.
2. Touch
the Hardcopy tab.
3. Touch the File button.
4. Touch inside the File Format field and select a file type.
5. Under Colors, touch the Use Print Colors checkbox if you want your waveforms to print in
color with a white background. A white background saves printer toner.
6. Touch inside the Directory field and type in the path to the directory where you want the
image stored, using the pop-up keyboard. Or you can touch the browse button and
navigate there.
7. Touch inside the File Name field and type in a name for your image, using the pop-up
keyboard.
8. Under Include On Print, touch the Grid Area Only checkbox if you do not want to include
the dialog area in the image.
9. Touch the Print Now button.
Saving and Recalling Waveforms
Saving Waveforms
1. In the menu bar, touch File; then touch Save Waveform... in the drop-down menu.
2. In the "Save Waveform" dialog, touch the Save To Memory or File
button.
3. Touch inside the Source field and select a source from the pop-up menu. The source can
be any trace; for example, a channel (C1C4), math function (F1F4), or a waveform stored
in non-volatile RAM (M1M4).
4. Touch inside the Trace Title data entry field if you want to change the default name of your
waveforms. Use the pop-up keyboard to type in the new name.
Note: You can change the name but not the sequence number.
CAUTION
