Teledyne LeCroy WaveExpert 100H Operators Manual - Manual (Page 171)

Wave Expert
WE-OM-E Rev A
169
Standard parameter.
Max populate Peak with maximum
population in a histogram. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
Mean Average of data for time
domain waveform.
Computed as centroid of
distribution for a histogram. Average of data Gives similar result
when applied to time
domain waveform or
histogram of data of
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Standard parameter.
Median The average of base and top
values. Average of Base and
Top. Standard parameter.
Minimum Measures the lowest point in
a waveform. Unlike base,
does not assume waveform
has two levels. Lowest value in
waveform between
cursors Gives similar result
when applied to time
domain waveform or
histogram of data of
same waveform. But
with histograms, result
may include
contributions from more
than one acquisition.
Standard parameter.
Mode Position of the highest
histogram peak. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
Nb phase Provides a measurement of
the phase at a specific
frequency of a waveform
(narrow band). Available with DDM2
and XMAP options.
Standard in
DDA-5005A.
Nb Power Provides a measurement of Available with DDM2
