Operator’s Manual
160
WE-OM-E Rev A
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Duty cycle Duty cycle: Width as
percentage of period. width/period Standard parameter.
Dwidth@level Difference of adjacent width
above or below a specified
level. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Edge@level Number of edges in
waveform. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Excel Performs measurements in
Excel by transferring one or
two waveforms and reading
the resulting parameter
value. Available with XMAP
option.
Excel must be loaded
on the instrument.
