Operator’s Manual
164
WE-OM-E Rev A
Hist rms Root mean square of the
values in a histogram. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
Hist sdev Standard deviation of values
in a histogram. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
Hist top Value of the right-most of the
two most populated
histogram peaks. Available with DDM2,
JTA2, and XMAP
options.
Standard in
DDA-5005A.
Hold time Time from the clock edge to
the data edge. You can set
levels, slope, and hysteresis
independently for Hold Clock
and Hold Data. See also
Setup parameter. Reference levels and
edge-transition polarity
can be selected.
Hysteresis argument
used to discriminate
levels from noise in
data.
Available with JTA2 and
XMAP options.
Last Time from trigger to last
(rightmost) cursor. Time from trigger to last
cursor Indicates location of
right cursor. Cursors
are interchangeable: for
example, the right
cursor may be moved to
the left of the left cursor
and first will give the
location of the cursor
formerly on the left, now
on right.
Standard parameter.
Level@X Gives the vertical value at
the specified x position. If the
x
position is between two
points, it gives the
interpolated value. When the
Standard parameter.
