Operator’s Manual
28
WE-OM-E Rev A
and math traces
Grid Styles: Single, Dual, Quad, Octal, XY, Single+XY, Dual+XY
Waveform Display Styles: Sample dots joined or dots only
Analog Persistence Display
Analog and Color-graded Persistence: Variable saturation levels; stores each trace's
persistence data in memory
Persistence Selections: Select analog, color, or 3-D
Trace Selection: Activate Analog Persistence on all or any combination of traces
Persistence Aging Time: From 500 ms to infinity
Sweeps Displayed: All accumulated or all accumulated with last trace highlighted
Zoom Expansion Traces
Display up to 4 Zoom and 4 Math/Zoom traces; 8 Math/Zoom traces available with XMAP (Master
Analysis Package) and XMATH (Advanced Math Package) options.
Rapid Signal Processing
Processor: Intel Pentium * 4 @ 2.53 GHz (or better) with MS Windows † XP Platform
Processor Memory: 2 G bytes
Internal Waveform Memory
Waveform: M1, M2, M3, M4 (Store full-length waveforms with 16 bits/data point.) Or save to any
number of files (limited only by data storage media).
Setup Storage
Front Panel and Instrument Status: Save to the internal hard drive, floppy drive, or to a USB
connected peripheral device.
Interface
Remote Control: Through Windows Automation or LeCroy Remote Command set, supports front
panel controls and internal functions via GPIB or Ethernet.
GPIB Port (optional): Supports IEEE-488.2
Ethernet Port: 10/100Base-T Ethernet interface
USB Ports: 6 USB ports (2 on the front panel) support Windows compatible devices.
External Monitor Port (standard): 15-pin D-Type SVGA compatible
* Registered trademark of Intel Corp.
† Registered trademark of Microsoft Corp.
