Page 86
Chapter 2. Operation
F1 F2 F3 F4
Play 3 [Prog Status]
ERR _ STEP [ NONE ] [ RUN ]
In Out Flag
23-4 Input/Output, Flag Status Display Mode (Step
23. F4)
F1- Input Status Display Mode (P86. 23-4-1)
F2- Output Status Display Mode (P86. 23-4-2)
F3- Flag Status Display Mode (P86. 23-4-3)
23-4-1 Input Status Display Mode (Step 23-4. F1)
Display In 002 is ON.
0 0 1 0 0 0 0 0 0 0
в в в
000 001 002 009 Я Port No.
23-4-2 Output Status Display Mode (Step 23-4. F2)
Display Out 301 is ON.
23-4-3 Flag Status Display Mode (Step 23-4. F3)
F1 F2 F3 F4
F1 F2 F3 F4
F1 F2 F3 F4
Play 012345678 (Flag)
600 -> 000000000 <-609
610 -> 000000000 <- 619
Inc
Dec
Play 012345678 (Out)
300 -> 010000000 <-309
310 -> 000000000 <- 319
Inc
Dec
Play 012345678 (In)
000 -> 001000000 <-009
010 -> 000000000 <--019
Inc
Dec
