Page 202
Chapter 4. Programming
(4) Application Program
Step A/O N OP-Code Operand1 Operand2 Post Comment
1 TAG 1
2 INB 15 1 Digital Switch Value into Variable 99
3 OUTB 302 1 Up-Take Value 7 Segment Output
4 CPEQ 99 1 601 When Up-Take Value = 1, Flag 601 ON
5 601 BTON 311 When Flag 601 ON, Lamp 1 ON
6 N601 BTOF 311 When Flag 601 OFF, Lamp 1 OFF
7 CPEQ 99 2 602 When Up-Take Value = 2, Flag 602 ON
8 602 BTON 312 When Flag 602 ON, Lamp 2 ON
9 N602 BTOF 312 When Flag 602 OFF, Lamp 2 OFF
10 CPEQ 99 3 603 When Up-Take Value = 3, Flag 603 ON
11 603 BTON 313 When Flag 603 ON, Lamp 3 ON
12 N603 BTOF 313 When Flag 603 OFF, Lamp 3 OFF
13 CPEQ 99 4 604 When Up-Take Value = 4, Flag 604 ON
14 604 BTON 314 When Flag 604 ON, Lamp 4 ON
15 N604 BTOF 314 When Flag 604 OFF, Lamp 4 OFF
16 CPEQ 99 5 605 When Up-Take Value = 5, Flag 605 ON
17 605 BTON 315 When Flag 605 ON, Lamp 5 ON
18 N605 BTOF 315 When Flag 605 OFF, Lamp 5 OFF
19 CPEQ 99 6 606 When Up-Take Value = 6, Flag 606 ON
20 606 BTON 316 When Flag 606 ON, Lamp 6 ON
21 N606 BTOF 316 When Flag 606 OFF, Lamp 6 OFF
22 CPEQ 99 7 607 When Up-Take Value = 7, Flag 607 ON
23 607 BTON 317 When Flag 607 ON, Lamp 7 ON
24 N607 BTOF 317 When Flag 607 OFF, Lamp 7 OFF
25 CPEQ 99 8 608 When Up-Take Value = 8, Flag 608 ON
26 608 BTON 318 When Flag 608 ON, Lamp 8 ON
27 N608 BTOF 318 When Flag 608 OFF, Lamp 8 OFF
28 CPEQ 99 9 609 When Up-Take Value = 9, Flag 609 ON
29 609 BTON 319 When Flag 609 ON, Lamp 9 ON
30 N609 BTOF 319 When Flag 609 OFF, Lamp 9 OFF
31 GOTO 1 Jump TAG 1
