Page 151
SQR (Square Root)
Chapter 4. Programming
E x p a n s io n
c o n d itio n
( A N D · O R )
In p u t
c o n d itio n
( I/O · F la g )
C o m m a n d
P o s t
( O u tp u t p o r t · F la g )
C o m m a n d O p e r a n d 1 O p e r a n d 2
O p tio n a l O p tio n a l S Q R V a r ia b le n o . D a ta ·V a r ia b le n o . O p tio n a l
[Function] Stores the square root (SQR) of the data in Operand 2 in the variable in Operand 1. Stores the square root of the
contents in the variable in Operand 2 in the Operand 1 variable. If there is a post instruction (flag, output port),
it turns ON when the computation result is zero.
[Example] SQR 1 4
The square root of 4 is 2, and after performing the command, variable 1 becomes 2.
SQR 1 *2
When the content of variable*2 in Operand 2 is 4, then the square root of 4 is 2, and after performing the
command variable 1 becomes 2.
