22-5 Execution, Stop Mode (22-3, F2)
Input program number to be executed or stopped.
Returns to 22-3.
Play 1-1 [ 50]
MOVP 1
699 A N499
Inc Dec Clr
F1 F2 F3 F4
Play 1 [Run 1- 0]
Prog
F1 F2 F3 F4
Play 1- 1 [ 50]
MOVP 1
699 A N499
In Out Flag Etc
F1 F2 F3 F4
Play 0123456789 (In)
000 ->1000000001 <-009
010->1000001100<-019
Inc
Dec
F1 F2 F3 F4
F1 F2 F3 F4
Play 0123456789 (Out)
300 ->1000000001 <-309
310->0000001100<--319
Inc
Dec
22-9 Play Output Display (22-7. F2)
F1- Output +10
F2- Output -10
22-8 Play Input Port Display (22-7. F1)
F1- Input Port +10
F2- Input Port -10
22-7 I/O port, Flag Status Selection Mode (22-3. F4)
F1- Input port change display, select (P82. 22-8)
F2- Ouput port change display, select (P82. 22-9)
F3- Flag change display, select (P83. 22-10)
F4- Execute, status selection screen (P83. 22-12)
