Page 43
Nippon Molex 53258-1420 (14P) (Body side)
51067-1400 Housing (14P)
50217-8100 x 14 Terminal
Chapter 1. Setting Up
†
SEL NET SND Connector (Option)
Nippon Molex 53259-0620 (6P) (Body side)
51067-0600 Housing (6P)
50217-8100 x 6 Terminal
‡
SEL NET RCV Connector (Option)
Nippon Molex 53259-0620 (6P) (Body side)
51067-0600 Housing (6P)
50217-8100 x 6 Terminal
M·PG Connector (Motor/Encoder Signal)
Y (2) Axis
Y (2) Axis
Pin No. Signal
1 MB
2 NC
3 NC
4 MA
5 FG
6 PV5
7 GD
8 A
9 AGN D
10 B
11 BGN D
12 Z
13 ZGN D
14 FG
P in N o. S ignal
1 N C
2 N C
3 R D
4 T D
5 G D
6 F G
P in N o . S ig na l
1 N C
2 N C
3 R D
4 T D
5 G D
6 F G
