Page 2 9-A
Chapter 1. Setting Up
4. Interface List (PNP Sourcing)
Emergency Stop is a b-contact in-
put (normally closed). To release
the emergency stop, short circuit
the jumper post with the jumper pin.
Refer to Supplement 7.
Pin No.3A (Port No.003), and Pin
No.3B (Port No.004) cannot be used
as user inputs.
Connector: Sumitomo 3M 7950-
6500SC or Yamaichi FAP-5001-
1202. *
*
*
P in N o . C a te g o ry P o rt N o . F u n ctio n C a b le C o lo r
1 A N 2 4 E xte rn a l p o w e r 0 V 1 -B ro w n
1 B
In p u t
0 0 0 E xte rn a l s ta rt in p u t 1 -R e d
2 A 0 0 1 U se r in p u t 1 -O ra n g e
2 B 0 0 2 E m e rg e n cy S to p b co n ta ct in p u t *1 1 -Ye llo w
3 A 0 0 3 S yste m re se rv e 1 -G re e n
3 B 0 0 4 S yste m re se rv e 1 -B lu e
4 A 0 0 5 U se r in p u t 1 -P u rp le
4 B 0 0 6 U se r in p u t 1 -G ra y
5 A 0 0 7 U se r in p u t 1 -W h ite
5 B 0 0 8 P R G N o . 1 (u se r in p u t) 1 -B la ck
6 A 0 0 9 P R G N o . 2 (u se r in p u t) 1 -B ro w n
6 B 0 1 0 P R G N o . 4 (u se r in p u t) 2 -R e d
7 A 0 11 P R G N o . 8 (u se r in p u t) 2 -O ra n g e
7 B 0 1 2 P R G N o . 1 0 (u se r in p u t) 2 -Ye llo w
8 A 0 1 3 P R G N o . 2 0 (u se r in p u t) 2 -G re e n
8 B 0 1 4 P R G N o . 4 0 (u se r in p u t) 2 -B lu e
9 A 0 1 5 U se r in p u t 2 -P u rp le
9 B 0 1 6 U se r in p u t 2 -G ra y
1 0 A 0 1 7 U se r in p u t 2 -W h ite
1 0 B 0 1 8 U se r in p u t 2 -B la ck
11 A 0 1 9 U se r in p u t 3 -B ro w n
11 B 0 2 0 U se r in p u t 3 -R e d
1 2 A 0 2 1 U se r in p u t 3 -O ra n g e
1 2 B 0 2 2 U se r in p u t 3 -Ye llo w
1 3 A 0 2 3 U se r in p u t 3 -G re e n
1 3 B
O u tp u t
3 0 0 E m e rg e n cy sto p /A la rm o u tp u t 3 -B lu e
1 4 A 3 0 1 R e a d y o u tp u t 3 -P u rp le
1 4 B 3 0 2 U se r o u tp u t 3 -G ra y
1 5 A 3 0 3 U se r o u tp u t 3 -W h ite
1 5 B 3 0 4 U se r o u tp u t 3 -B la ck
1 6 A 3 0 5 U se r o u tp u t 4 -B ro w n
1 6 B 3 0 6 U se r o u tp u t 4 -R e d
1 7 A 3 0 7 U se r o u tp u t 4 -O ra n g e
1 7 B 3 0 8 U se r o u tp u t 4 -Ye llo w
1 8 A 3 0 9 U se r o u tp u t 4 -G re e n
1 8 B 3 1 0 U se r o u tp u t 4 -B lu e
1 9 A 3 11 U se r o u tp u t 4 -P u rp le
1 9 B 3 1 2 U se r o u tp u t 4 -G ra y
2 0 A 3 1 3 U se r o u tp u t 4 -W h ite
2 0 B 3 1 4 U se r o u tp u t 4 -B la ck
2 1 A 3 1 5 U se r o u tp u t 5 -B ro w n
2 1 B 3 1 6 U se r o u tp u t 5 -R e d
2 2 A 3 1 7 U se r o u tp u t 5 -O ra n g e
2 2 B 3 1 8 U se r o u tp u t 5 -Ye llo w
2 3 A 3 1 9 U se r o u tp u t 5 -G re e n
2 3 B 3 2 0 U se r o u tp u t 5 -B lu e
2 4 A 3 2 1 U se r o u tp u t 5 -P u rp le
2 4 B 3 2 2 U se r o u tp u t 5 -G ra y
2 5 A 3 2 3 U se r o u tp u t 5 -W h ite
2 5 B P 2 4 E xte rn a l p o w e r + 2 4 V 5 -B la ck
