How to Configure the Video Delay Parameters of a
Play Channel
To configure the Video Delay Parameters of a Play Channel, proceed as follows:
1. Select the play channel to configure by pressing
ALT+the corresponding F_ key on
the PC keyboard (ex: ALT+F1 for PGM1, ALT+F2 for PGM2/PRV, etc)
2. If you want to use another server on the SDTI network as a source, press SHIFT + F7
on the PC keyboard to call up the network list. Use the arrow keys to select a server,
and press ENTER to validate.
3. Select the camera angle: use the left / right arrow keys, or the key to move
the green cursor on the desired camera, the press ENTER. The new camera angle is
loaded on the channel.
4. Set the new value for the delay: use the left / right arrow keys, or the key to
move the green cursor over the TARGET DELAY field, and enter the desired delay
value in hh:mm:ss:fr. Press CTRL+the corresponding F_ key on the PC keyboard to
activate the new delay on the selected channel (ex: CTRL + F1 start the new delay
on PGM1). If the duration of the record train is lower than the target delay, the
channel will pause on the first recorded picture until the record train is long enough
for the desired delay. In this case, the message “WAIT” is displayed on the OSD of
that channel.
