Multicam - Version 11.01 – Operating Manual

EVS Broadcast Equipment SA – November 2012

Issue

11.01.D

cue points by turning the jog dial.
When the current picture on the primary channel is neither a clip nor a cue point, or if the

operator is in Playlist mode, pressing the

BROWSE key allows him to browse inside the

clips of the current playlist by turning the jog dial.

4.1.12 INSERT

This function inserts a clip before or after (depending on the

Setup menu) the current

position inside the playlist.

4.1.13 ENTER

This function appends clip(s) at the end of the current playlist. This is also used to confirm

saving of clips, and validate various options and messages.

4.1.14 MENU

This function allows the operator to gain access to the secondary menu.
SHIFT+MENU on the Remote gains access to the main menu.
Also used as an

ESCAPE key to cancel some options and messages.

4.1.15 CLEAR

This function clears the IN / OUT/ playlist / CLIPS / CUE points.

Note

•

To clear one CUE point, recall the desired cue point and press

CLEAR+MARK key.

•

To clear all cues: when current picture is not a CUE point, press

CLEAR+MARK key. A message appears to confirm the command.

4.1.16 NETWORK

This function gives access to the clips and/or records trains of other machines on the

network. After the selection of the machine, the way of selecting clips and camera angles

is similar to clips selection on the local LSM system. Refer to the Chapter 13 ‘Operating

on XNet Network’, on page 151 for more details.
