16.3 How to Edit an Offside Line
Once the offside line has already been created, you can still load the sequence and edit
it.
To edit an existing offside sequence, proceed as follows:
1. In the Offside Line mode, press
Last Cue until you reach the cue corresponding to
the requested offside sequence.
The following menu is displayed on the Remote Panel:
2. Press the A key (Edit).
3. Jog to move the pivot point to the position where you want to break the line.
4. Press
TAKE to fix the pivot point.
5. Jog to break the line and change its inclination from the pivot point.
6. Repeat steps 3 to 5 for each new pivot point you want to define.
7. Press
Mark to validate your changes.
16.4 How to Play the Offside Sequence
Once the offside line has been defined, you can play it as long as you are in Offside Line
mode. It will be played based on the settings defined in the secondary menu. For more
information, see the section 16.1.4 ‘Overview on the Offside Line Commands’, on page
170.
To play back an existing offside sequence, proceed as follows:
1. In the offside mode, press
Last Cue until you reach the preroll cue for the requested
offside sequence.
2. Press PLAY to play the sequence.
The offside sequence is replayed according to the speed defined by the operator. When
the sequence reaches the keyframe, it is paused and the offside line is displayed
according to the fade in/out duration and the pause duration defined in the secondary
menu. You need to move the lever or press PLAY on the Remote Panel.
OSD QUIT
EDIT SIDE UNDO
