11.18.6 Loop Mode in the Replace Function
Loop Type
When the IN point has been marked, the display switches to:
Cam A
+2fields
Replace Int.Loop Ext.Loop
The Int. Loop and Ext. Loop keys are blinking.
Before entering the Replace Playback mode, the operator has to choose between Internal
Loop or External Loop.
The Internal Loop is the same loop as the existing loop process.
The External Loop allows you to select on which channel you will physically re-record the
output of your PGM. The link is physical: it is necessary to make the video link manually
with a router or video/audio cables; it is not done inside the server.
Additional Loop Parameters
Additional parameters are available for the external loop:
•
With the
Cam A function (SHIFT+C), you can select the camera the PGM will be
recorded to for the external LOOP process. Press SHIFT+C until the desired camera
is selected.
•
With the
+2 fields function (SHIFT+D), you can select by how much the video coming
back to your record channel will be delayed. If you are using a DVE, it could introduce
a delay. This system is based on the assumption that audio and video are in sync
when they hit the record channel. The delay value cannot be negative.
Select SHIFT+D to highlight the delay value; the display allows you to add frames or
fields of delay to the delay value. Pressing either
MENU or SHIFT+D will leave this
mode.
