Multicam - Version 11.01 – Operating Manual
EVS Broadcast Equipment SA – November 2012
Issue
11.01.D
163
15. Target Mode
15.1 Introduction
Note
The Target mode is a software option, which requires the license code 114
being installed. For more information on the required license key, contact the
Support or Sales team.
The Target mode is not available on EVS servers working with 10-bit codecs.
This software option enables the tracking of an object/action by use of a circle, arrow,
ellipse or rectangle 1 , focusing the attention on certain details. The user can choose the
size, color and thickness of the border as well as the darkness of the background for a
highlight feature. The addition of the Loop function allows the operator to store this effect
as a clip.
The facilities within this software package can be operated using the tablet and the stylus,
or a touch screen. Change the Pointing device parameter in the Operational Setup
menu (p.9.2 F2) to toggle between the tablet and the touch screen (only when the touch
screen is available). The touch screen must always be connected to the RS422 port #6
and defined with the RS422 #6 parameter in the Operational Setup menu (p.T2.2 F6).
1 In this chapter, we use the words “tracking object” to refer to the type of shape selected by the
operator (circle, arrow, ellipse or rectangle).
